Description
FEATURES:
WIRE RANGE – .047″ TO .148″
CONST. COIL OD. RANGE – 1/4″ TO 2-3/4″
SPEED – 7 TO 180 SPRINGS PER MINUTE
WIRE LENGTH PER SPRING:
STD – 0″ TO 60″ – .148″ MAX WIRE DIAMETER
SPEC – 0″ TO 91″ – .120″ MAX WIRE DIAMETER
SPEC – 0″ TO 127″ – .093″ MAX WIRE DIAMETER
O.A. DIMENSIONS: 6’3″ X 4’4″X 6′ HIGH X 4,800 LBS.
EQUIPPED WITH 7 ROLL HORIZONTAL & 7 ROLL VERTICAL PLANE STRAIGHTENER
EXTRA CAMS AND GEARS
5HP 220/440V/3PH/60 CYC/1200 RPM VARIDRIVE, W/CONTROLS
